CRS125-24G-1S-2HnD-IN: 24 port GbE smart switch with 1SFP + WiFi

Perfect SOHO gateway router, switch, 802.11n Wireless Access Point all in one box

Cloud Router Switch is our new Smart Switch series. It is a fully functional Layer 3 switch, and is powered by the familiar RouterOS.

All the specific Switch configuration options are available in a special Switch menu, but if you want, ports can be removed from the switch configuration, and used for routing purposes.

What’s more - this device has a built in 2.4GHz wireless access point, this means you can have an AP, a router with any number of ports, and a full wire speed smart switch, all in one device - ideal for medium/small businesses and offices. It has 24 Gigabit ports, one SFP cage, a microUSB port and a built in Wireless AP.

• Fully manageable L3 switch, full wire speed switching
• Wireless AP built in
• Configure ports as switch, or for routing
• If required, full RouterOS power right there

CRS125-24G-1S-2HnD-IN
CPU
Qualcomm Atheros AR9344 600 MHz
Memory 128MB
Ethernet ports
24x 10/100/1000 Mbit/s Gigabit Ethernet with Auto-MDI/X
Expansion
microUSB port
Serial Port One RJ45 serial port
Storage
128MB Onboard NAND with multiple OS partition support
Temp range
-35C to +65C tested
Power
 24-volt 30-Watt PSU included.
Extras

Reset switch; beeper; voltage and temperature monitoring, touchscreen LCD

Dimensions
285x145x45mm
Software MikroTik RouterOS v6, Level 5 license

  Product Data Sheet



General
Name CRS125-24G-1S-2HnD-IN
Can be used indoors Yes
Certification CE, FCC, EAC, ROHS
Dimensions 285 x 167 x 44 mm
FAN count Passive
IP IP20
MTBF Approximately 200'000 hours at 25C
Tested ambient temperature -30°C to 60°C
Interfaces
10/100/1000 Ethernet ports 24
SFP ports 1
SFP DDMI Yes
Serial port RJ45
OS
Operating System RouterOS
RouterOS license 5
CPU
Architecture MIPSBE
CPU AR9344
CPU core count 1
CPU nominal frequency 600 MHz
Board
Size of RAM 128 MB
Storage size 128 MB
Storage type NAND
PCB temperature monitor Yes
Voltage Monitor Yes
Powering
DC jack input Voltage 8-28 V
Max power consumption 19 W
Number of DC inputs 2
PoE
PoE in Passive PoE
PoE in input Voltage 8-28 V
USB
Max USB current (A) 1
Number of USB ports 1
USB Power Reset Yes
USB slot type microUSB type AB
Wireless
802.11b Yes
802.11g Yes
802.11n Yes
Antenna gain 4
Antenna header count 2
TX power
2.4 GHz
TX RX
1MBit/s 29 -97
11MBit/s 28 -90
6MBit/s 30 -96
54MBit/s 25 -76
MCS0 30 -96
MCS7 23 -73
Wi-Fi generation Wi-Fi 4
Wireless 1 Max data rate 300 Mbit/s
Wireless 1 Number of chains 2
Wireless 1 band 2.4 GHz
Wireless 1 generation Wi-Fi 4
Wireless chip model AR9344
Wireless standards 802.11b/g/n
